Claw Crane Machine crane failure is one of the most frequently encountered problems when grasping crane machines, and it is also a very critical problem. Because the Claw Crane Machine crane has problems, it will directly affect the player’s experience. Let’s ask if the player’s claws do not obey and delay when manipulating the crown block, how much experience will be lost. Therefore, businesses must also learn to troubleshoot and solve the malfunction of the crane crane on their own.
The following formally begins to share dry goods, on the analysis and troubleshooting of common problems of the Claw Crane Machine crane:
1. Overhead crane inspection
Those who have just started the crane machine industry must know that the cranes of the newly bought crane machines have cable ties. This is to prevent the claw machine from shaking and damaging the machine during transportation. That’s why it is tied up with a cable tie. So don’t put it in the mall as soon as you buy it, because the crane won’t move without cutting the cable tie.
In addition, it is necessary to insist on whether there is any problem with the nine-square grid linking the crane. Whether there is any looseness, peel off the docking Jiugongge crane to be independent.
2. Route investigation
The purpose of wiring inspection is to confirm whether there are problems with the wiring and the motherboard. Because the motherboard will also affect the smoothness of the crane’s operation. Specific method: Push the crane crane next to the crane to the side and shut it down, connect the spare crane cable A to the problematic crane crane, and connect the B end of the crane cable to the motherboard of the crane crane next to it. The good claw machine is turned on.
3. Try coin-operated
If the crane can start normally, it is a line problem. If the line and the crane are changed, the crane still cannot operate normally, it is a motherboard problem. If all the components are replaced and checked, it is a problem with the crane.
4. Inspection of overhead line
Just replace the old crane and replace the new one. Tips for dismantling the crane: Unscrew the screws on both ends of the crane, raise the crane a bit diagonally, (left front and right rear) so that it can be removed The same is true of replacing a new crane.
If there is a problem with the line of the crane, replace the old line with the spare line to connect the main board and the nine-grid grid of the crane respectively, and start the trial and see if everything is normal.
5. Check the details of the crane crane
This is because many novices did not think of this layer when they bought the machine, or the price was run-in, and they did not order some accessories. If there is a problem, they started to think. So troublesome.
6. Crane motor
Push the crown block to the middle, pull down the claw’s rope a little, and turn it on. After the crane machine program is turned on, the crane will return to its position. Use this to detect the three motors of the crane to see which is the problem. The three motors control the movement of the crane back and forth, left and right, and the claws up and down. If the exercise is not done, it is because there is a problem with the motor. For example, if the claw is pulled down, the crane is in place, and the claw is still hanging in the air, there is a problem with the motor. Sending it back to the manufacturer is too heavy, and the postage is also a lot. If you have a motor, you can buy one from the original manufacturer. You can also check whether the gears of the motor and the wheels of the crown block are properly connected. If everything is ok, remove the motor and replace it with a new one.
